ISO 2531 ductile iron pipe manufactured by vortex are mainly used for transferring the drinkable water,waste water and for irrigation.
The diameter is from DN80-DN2000,K8/K9/K10/K12, Tyton socket and spigot,the standard length is 6m.
ISO 2531 ductile iron pipe manufactured by vortex are mainly used for transferring the drinkable water,waste water and for irrigation.
The diameter is from DN80-DN2000,K8/K9/K10/K12, Tyton socket and spigot,the standard length is 6m.
| Product name: | Ductile Iron Pipe |
| Standard: | ISO2531, EN545 , EN598. |
| Pipe class: | K9, K8, C40, C30, C25, etc. |
| Pipe joint: | Push-on joint(Tyton joint), K type joint, self-restrained joint |
| Effective length: | 6m, cut to 5.7m. |
| In general, the pipe length is 6m for bulk shipment and 5.7m for container shipment. | |
| Material: | Ductile Cast Iron GGG50 |
| Pressure: | PN10, PN16, PN25,PN40 |
| Application: | Water supply project, drainage, sewage, irrigation, water pipeline. |
| Internal Coating: | a). Portland cement mortar lining |
| b). Sulphate Resistant cement mortar lining | |
| c). High-Aluminum cement mortar lining | |
| d). Fusion bonded epoxy coating | |
| e). Liquid epoxy painting | |
| f). Black bitumen painting | |
| External Coating: | a). zinc+bitumen(70microns) painting |
| b). Fusion bonded epoxy coating | |
| c). Zinc-aluminum alloy +liquid epoxy painting | |
| Packing: | Bundled with steel belts or in bulk |
| Inspection | Factory Inspection certificate will be issued for every shipments. |
| Note: The coating can also be accordance with customers’ requirements. | |
